930-9DHAR-0001-000 - Nvidia BlueField-3 PCIe Auxiliary Kit, PCIe Gen 5, 150mm Cabline, FRU harness - New

930-9DHAR-0001-000 - Nvidia BlueField-3 PCIe Auxiliary Kit, PCIe Gen 5, 150mm Cabline, FRU harness - New
930-9DHAR-0001-000 - Nvidia BlueField-3 PCIe Auxiliary Kit, PCIe Gen 5, 150mm Cabline, FRU harness - New

Nvidia

SKU: 930-9DHAR-0001-000

Please Call for Price & Availability.

← Previous Product Next Product →

Manufacturer: Nvidia
Manufacturer Ordering Part #: 930-9DHAR-0001-000
Condition: NEW
Availability: Call For Availability

NVIDIA BlueField-3 PCIe Auxiliary Card Kit - 150mm Gen 5.0 FRU harness, Cabline SA-II Plus 60-pin micro coax 38AWG

The self-hosted BlueField-3 DPU controllers with downstream port extension option integrate a single network adapter silicon on a primary board, and an auxiliary PCIe connection card and Cabline SA-II Plus Harness connecting the two. Utilizing the Down Stream Port (DSP) extension option, where the PCIe extension card is connected to the BlueField-3 DPU, used as a root complex for storage devices.
This enables direct access from each CPU to the network through its dedicated PCIe interface as the card's 32-lane PCIe bus is split into two 16-lane buses, with one bus accessible through a PCIe x16 edge connector and the other bus through an x16 Auxiliary PCIe Connection card. The two cards should be installed into two PCIe x16 slots and connected using two Cabline SA-II Plus harnesses.
The PCIe auxiliary kit can be purchased separately to allow downstream port extension.
